Default 488.5 WHP / 548 WTQ - Dyno Dynamics - 10-29-2014, 06:24 AM

'07 FBO E92 Sport 335i - AFE Stage II Pro, ER CP, Forge DVs, HPF 7" FMIC, 455 LPFP, Stock ***** Back Exhaust, Aquamist HFS4, Stock Turbo...

E60 / 100% Meth

BQ Tuning by WedgePerformance

Special thanks to @BuraQ - We make a great team bro.

Just wanted to share if you haven't seen this on E90 already. Won't go into great detail, but the car is tuned using ATR.

DD dyno at PreRacing.com









Special thanks to...
Reply With Quote
(#2)
Old
dx1541 dx1541 is offline
Junior Member

Posts: 35
Join Date: Dec 2013
Car: 335i DCT
Default 10-29-2014, 06:33 AM

Holy smokes! 488 whp on a dd is some serious power man... Quickly hook me up with this map man, waiting for your mail to come in!
Reply With Quote
(#3)
Old
chuckd05 chuckd05 is offline
Junior Member

Posts: 296
Join Date: Sep 2011
Car: 08 135i , 06 325xi e90
Default 10-29-2014, 06:42 AM

Get it on a DynoJet...

I dynoed 342 in my 370z on a dynodynamics dyno at a shop near me, than went to a dynojet and dynoed 312

Or have the car trap 123 either one will validate it


e92
Reply With Quote
(#4)
Old
Terry @ BMS's Avatar
Terry @ BMS Terry @ BMS is offline
Tuner

Posts: 32,569
Join Date: Jan 2008
Default 10-29-2014, 08:07 AM

Nice runs Ken but sorry to break some bad news. This is not a dyno record. Dyno records can only be set on dynojet machines. It's because DD, MD, and other types of dynos show wildly varying numbers based on their correction factors and other settings. I have had customers email in reporting 500whp on DD machines stock turbo, lol. It's meaningless. It needs to be done on a dynojet to count which has proven to be very consistent day to day and machine to machine. And most importantly there are no settings to adjust to get higher or lower figures.

In fact I think we had this same conversation 2-3 years ago at shift sector when you told me you dynod at 500whp on stock turbos. And I said it was impossible. Turns out you were using an MD dyno and when you went to a dynojet only did 440whp, if memory serves? For tuning MD & DD are fine. But for records its dynojet or nothing.

Anyway go run it on a dynojet and you'll probably get the same 450-460whp everyone else gets running the same boost and timing levels. Maybe you'll even break our record. But to get up to 480whp for the current stock record we really had to pull out all the stops! It can be repeated but it won't be with an automatic IMHO.


Burger Motorsports
Home of the JB4 the worlds most popular turbocharged tuning system!

It is the sole responsibility of the purchaser and installer of any BMS part to employ the correct installation techniques required to ensure the proper operation of BMS parts, and BMS disclaims any and all liability for any part failure due to improper installation or use. It is the sole responsibility of the customer to verify that the use of their vehicle and items purchased comply with federal, state and local regulations. BMS claims no legal federal, state or local certification concerning pollution controlled motor vehicles or mandated emissions requirements. BMS products labeled for use only in competition racing vehicles may only be used on competition racing vehicles operated exclusively on a closed course in conjunction with a sanctioned racing event, in accordance with all federal and state laws, and may never be operated on public roads/highways. Please click here for more information on legal requirements related to use of BMS parts.
Reply With Quote
(#5)
Old
boost junkie boost junkie is offline
Junior Member

Posts: 177
Join Date: Jul 2013
Car: bmw
Default 10-29-2014, 08:54 AM

Quote:
Originally Posted by Terry @ BMS
Nice runs Ken but sorry to break some bad news. This is not a dyno record. Dyno records can only be set on dynojet machines. It's because DD, MD, and other types of dynos show wildly varying numbers based on their correction factors and other settings. I have had customers email in reporting 500whp on DD machines stock turbo, lol. It's meaningless. It needs to be done on a dynojet to count which has proven to be very consistent day to day and machine to machine. And most importantly there are no settings to adjust to get higher or lower figures.
You mean like the guy that just made 521whp/634 ftlbs on stock turbos?
Reply With Quote
(#6)
Old
Terry @ BMS's Avatar
Terry @ BMS Terry @ BMS is offline
Tuner

Posts: 32,569
Join Date: Jan 2008
Default 10-29-2014, 09:02 AM

Quote:
Originally Posted by boost junkie
You mean like the guy that just made 521whp/634 ftlbs on stock turbos?
lol yeah. FWIW even dynojets can be flawed but its obvious when they are. If you dyno at a high elevation SAE & STD corrections inflate the numbers. Like up to 10%. But it's easily viewable in the DRF file. I've had other "500whp stock turbo" results reported that way. With a DJ there is sort of an unwritten rule that the SAE or STD correction factor needs to be within 5% for it to count.


Burger Motorsports
Home of the JB4 the worlds most popular turbocharged tuning system!

It is the sole responsibility of the purchaser and installer of any BMS part to employ the correct installation techniques required to ensure the proper operation of BMS parts, and BMS disclaims any and all liability for any part failure due to improper installation or use. It is the sole responsibility of the customer to verify that the use of their vehicle and items purchased comply with federal, state and local regulations. BMS claims no legal federal, state or local certification concerning pollution controlled motor vehicles or mandated emissions requirements. BMS products labeled for use only in competition racing vehicles may only be used on competition racing vehicles operated exclusively on a closed course in conjunction with a sanctioned racing event, in accordance with all federal and state laws, and may never be operated on public roads/highways. Please click here for more information on legal requirements related to use of BMS parts.
Reply With Quote
(#7)
Old
Bobdudeman1988's Avatar
Bobdudeman1988 Bobdudeman1988 is offline
Junior Member

Posts: 448
Join Date: May 2012
Car: 07 E90 335i
Default 10-29-2014, 09:18 AM

Quote:
Originally Posted by boost junkie
You mean like the guy that just made 521whp/634 ftlbs on stock turbos?
i was that guy, im starting to believe my run was bad trust me. i cant make it to a dj this year but i will next year for sure, only way to find out



I AM BOB!
Reply With Quote
(#8)
Old
Newguy123's Avatar
Newguy123 Newguy123 is offline
Demigod

Posts: 1,785
Join Date: May 2014
Car: 12' 135i
Default 10-29-2014, 09:36 AM

all these crazy dynos numbers being posted lately and im in my N55 over here like


18 Glacier white RS3
#PURETURBOS
#FUELIT
Reply With Quote
(#9)
Old
Ando @ BMS's Avatar
Ando @ BMS Ando @ BMS is offline
BMS Customer Service

Posts: 738
Join Date: Jan 2013
Car: bmw 335i
Default 10-29-2014, 09:50 AM

yup. I believe 460whp be it. My AT dynoed 460whp on dynojet with pushing it hard.


Burger Motorsports
Home of the Worlds fastest N20s, N54s, N55s, N63s, and S63s!

It is the sole responsibility of the purchaser and installer of any BMS part to employ the correct installation techniques required to ensure the proper operation of BMS parts, and BMS disclaims any and all liability for any part failure due to improper installation or use. It is the sole responsibility of the customer to verify that the use of their vehicle and items purchased comply with federal, state and local regulations. BMS claims no legal federal, state or local certification concerning pollution controlled motor vehicles or mandated emissions requirements. BMS products labeled for use only in competition racing vehicles may only be used on competition racing vehicles operated exclusively on a closed course in conjunction with a sanctioned racing event, in accordance with all federal and state laws, and may never be operated on public roads/highways. Please click here for more information on legal requirements related to use of BMS parts.
Reply With Quote
(#10)
Old
Terry @ BMS's Avatar
Terry @ BMS Terry @ BMS is offline
Tuner

Posts: 32,569
Join Date: Jan 2008
Default 10-29-2014, 09:51 AM

Quote:
Originally Posted by Newguy123
all these crazy dynos numbers being posted lately and im in my N55 over here like
The sad part is our N55 dyno record of 480whp with the Vargas Stage2 turbo is basically on par with our N54 stock turbo record.

I know Vargas is making some N55 changes to the WG that may up the ante though.


Burger Motorsports
Home of the JB4 the worlds most popular turbocharged tuning system!

It is the sole responsibility of the purchaser and installer of any BMS part to employ the correct installation techniques required to ensure the proper operation of BMS parts, and BMS disclaims any and all liability for any part failure due to improper installation or use. It is the sole responsibility of the customer to verify that the use of their vehicle and items purchased comply with federal, state and local regulations. BMS claims no legal federal, state or local certification concerning pollution controlled motor vehicles or mandated emissions requirements. BMS products labeled for use only in competition racing vehicles may only be used on competition racing vehicles operated exclusively on a closed course in conjunction with a sanctioned racing event, in accordance with all federal and state laws, and may never be operated on public roads/highways. Please click here for more information on legal requirements related to use of BMS parts.
Reply With Quote
(#11)
Old
bnk bnk is offline
Junior Member

Posts: 474
Join Date: Jan 2008
Default 10-29-2014, 12:18 PM

Quote:
Originally Posted by Bobdudeman1988
i was that guy, im starting to believe my run was bad trust me. i cant make it to a dj this year but i will next year for sure, only way to find out
Why not try virtual dyno to get some more data points?
Reply With Quote
(#12)
Old
Peter @ Pure's Avatar
Peter @ Pure Peter @ Pure is offline
Demigod

Posts: 1,688
Join Date: Aug 2013
Car: F20 M135i
Default 10-29-2014, 02:52 PM

Quote:
Originally Posted by Terry @ BMS
The sad part is our N55 dyno record of 480whp with the Vargas Stage2 turbo is basically on par with our N54 stock turbo record.

I know Vargas is making some N55 changes to the WG that may up the ante though.
No need to rub it in we'll see what the future brings.


F21 M140i - 100-200: 5.18 60-130: 5.96
Audi TTRS - 100-200: 4.01 60-130: 4.5
F80 M3 - 100-200: 4.32, 60-130: 4.8
F20 M135i (sold) - 100-200: 6.26 , 60-130: 7.4
peter@pureturbos.eu
peter@pureturbos.com
peter@protuningfreaks.com
pureturbos.eu
Reply With Quote
(#13)
Old
musc's Avatar
musc musc is offline

Posts: 770
Join Date: Jan 2008
Car: 335is DCT
Default 10-29-2014, 05:59 PM

The only way these dynos can be validated is to have some kind of stock baseline same dyno, conditions, etc. Otherwise, stick it on a dynojet


335is DCT
Reply With Quote
(#14)
Old
Wedge1967's Avatar
Wedge1967 Wedge1967 is offline
Junior Member

Posts: 356
Join Date: Apr 2012
Car: '07 335i e92
Default 10-29-2014, 07:29 PM

Only reason I went back to pull on this dyno was the fact it was the only dyno I could get on two weeks ago when I pulled 444/503. So in two weeks we were able to find another 44 whp... When I get time I'll be hitting the dynojet at PSI. I've pulled 460 on that dyno before in the past. Car feels better now, but my butt dyno is getting old. hahahaha

Quote:
Originally Posted by Terry @ BMS
Nice runs Ken but sorry to break some bad news. This is not a dyno record. Dyno records can only be set on dynojet machines. It's because DD, MD, and other types of dynos show wildly varying numbers based on their correction factors and other settings. I have had customers email in reporting 500whp on DD machines stock turbo, lol. It's meaningless. It needs to be done on a dynojet to count which has proven to be very consistent day to day and machine to machine. And most importantly there are no settings to adjust to get higher or lower figures.

In fact I think we had this same conversation 2-3 years ago at shift sector when you told me you dynod at 500whp on stock turbos. And I said it was impossible. Turns out you were using an MD dyno and when you went to a dynojet only did 440whp, if memory serves? For tuning MD & DD are fine. But for records its dynojet or nothing.

Anyway go run it on a dynojet and you'll probably get the same 450-460whp everyone else gets running the same boost and timing levels. Maybe you'll even break our record. But to get up to 480whp for the current stock record we really had to pull out all the stops! It can be repeated but it won't be with an automatic IMHO.
Reply With Quote
(#15)
Old
Wedge1967's Avatar
Wedge1967 Wedge1967 is offline
Junior Member

Posts: 356
Join Date: Apr 2012
Car: '07 335i e92
Default 10-29-2014, 07:34 PM

Quote:
Originally Posted by Ando @ BMS
yup. I believe 460whp be it. My AT dynoed 460whp on dynojet with pushing it hard.
With the advanced tuning we're doing, we demanding more torque within a few tables... To my surprise it makes a big difference in the cars performance. We're making a lot more power with less timing. Our ATR Advanced Tuning is on par with PTF's tuning using ATP and Cobb Race Logic which removes some of the ceiling limits we have to deal with to get the boost we are making.
Reply With Quote
(#16)
Old
DSCOFF's Avatar
DSCOFF DSCOFF is offline
Senior Member

Posts: 534
Join Date: Jun 2013
Car: 335i coupe N54
Default 10-29-2014, 07:43 PM

Unfortunately in Australia, I cannot find anyone offering Dynojet dynos

And most of our Dyno Dynamics and Mainline dynos ones are always 15-20% under Dynojet results in the US especially if in shootout mode. But yeah, these dynos can be manipulated up or down for that matter quite easily.


2009 N54 335i coupe, 6AT PD trans, Stage 3 XHP, Built Motor, 9.6:1 Comp Ratio, Ported Head, Trebilia Custom Flash, JB4, Mhd flasher, Ngk 97506 0.018 gapped, PI Kit 100% E85, Jb4 PI integration, Stage 2 Pure Turbos 25.6psi, 17.2 deg timing, TFT inlets, Stage 3 Fuel-it Fpr, FBO, 431rwkw Mainline Dyno Aus

2016 M4 Competition Pack, 7-sp DCT, Jb4 Map 6
25.0 psi, s55 ign e85 Bef, E70, M4 plugs gapped 0.020, stock everything else, 374.9 rwkw Mainline Dyno Aus
Reply With Quote
(#17)
Old
DSCOFF's Avatar
DSCOFF DSCOFF is offline
Senior Member

Posts: 534
Join Date: Jun 2013
Car: 335i coupe N54
Default 10-29-2014, 07:52 PM

To put it in perspective, I achieved 451whp on a DD with my setup.. And my boost was 19.5 all the way to 5800 rpm and 18.5 at 6400 rpm with timing above 13 deg. this was on a 70 adder, zero ignition retard. LOL, a heartbreaker? Not when I see all the cars on that dyno and what they achieved before...


2009 N54 335i coupe, 6AT PD trans, Stage 3 XHP, Built Motor, 9.6:1 Comp Ratio, Ported Head, Trebilia Custom Flash, JB4, Mhd flasher, Ngk 97506 0.018 gapped, PI Kit 100% E85, Jb4 PI integration, Stage 2 Pure Turbos 25.6psi, 17.2 deg timing, TFT inlets, Stage 3 Fuel-it Fpr, FBO, 431rwkw Mainline Dyno Aus

2016 M4 Competition Pack, 7-sp DCT, Jb4 Map 6
25.0 psi, s55 ign e85 Bef, E70, M4 plugs gapped 0.020, stock everything else, 374.9 rwkw Mainline Dyno Aus
Reply With Quote
(#18)
Old
Wedge1967's Avatar
Wedge1967 Wedge1967 is offline
Junior Member

Posts: 356
Join Date: Apr 2012
Car: '07 335i e92
Default 10-29-2014, 08:03 PM

Quote:
Originally Posted by DSCOFF
To put it in perspective, I achieved 451whp on a DD with my setup.. And my boost was 19.5 all the way to 5800 rpm and 18.5 at 6400 rpm with timing above 13 deg. this was on a 70 adder, zero ignition retard. LOL, a heartbreaker? Not when I see all the cars on that dyno and what they achieved before...
They had a dyno day a week prior and all the stock cars were on target for what they would normally run on a Dynojet. Even a car on 92 pump with JB4 made 340 whp. Same tech, same setup..
Reply With Quote
(#19)
Old
trebila's Avatar
trebila trebila is offline
Legend

Posts: 1,280
Join Date: Mar 2013
Car: 135i
Default 10-30-2014, 07:05 AM

Quote:
Originally Posted by DSCOFF
To put it in perspective, I achieved 451whp on a DD with my setup.. And my boost was 19.5 all the way to 5800 rpm and 18.5 at 6400 rpm with timing above 13 deg. this was on a 70 adder, zero ignition retard. LOL, a heartbreaker? Not when I see all the cars on that dyno and what they achieved before...
great log.

as long as your AFRs stay between 12.6-12.9, your timing will be good.

can you do a 3-4 gear upshift with your AT, to check your postshift timing recovery ?


FBO N54 AT 135i 'vert with JB4 and Trebila Performance custom flash
Reply With Quote
(#20)
Old
DSCOFF's Avatar
DSCOFF DSCOFF is offline
Senior Member

Posts: 534
Join Date: Jun 2013
Car: 335i coupe N54
Default 10-30-2014, 07:28 AM

Yeah, I will do that test soon. I have a feeling I do not suffer from flat lining as much but I will have to do it on the dyno...


2009 N54 335i coupe, 6AT PD trans, Stage 3 XHP, Built Motor, 9.6:1 Comp Ratio, Ported Head, Trebilia Custom Flash, JB4, Mhd flasher, Ngk 97506 0.018 gapped, PI Kit 100% E85, Jb4 PI integration, Stage 2 Pure Turbos 25.6psi, 17.2 deg timing, TFT inlets, Stage 3 Fuel-it Fpr, FBO, 431rwkw Mainline Dyno Aus

2016 M4 Competition Pack, 7-sp DCT, Jb4 Map 6
25.0 psi, s55 ign e85 Bef, E70, M4 plugs gapped 0.020, stock everything else, 374.9 rwkw Mainline Dyno Aus
Reply With Quote
(#21)
Old
Terry @ BMS's Avatar
Terry @ BMS Terry @ BMS is offline
Tuner

Posts: 32,569
Join Date: Jan 2008
Default 10-30-2014, 08:33 AM

Quote:
Originally Posted by Wedge1967
Only reason I went back to pull on this dyno was the fact it was the only dyno I could get on two weeks ago when I pulled 444/503. So in two weeks we were able to find another 44 whp... When I get time I'll be hitting the dynojet at PSI. I've pulled 460 on that dyno before in the past. Car feels better now, but my butt dyno is getting old. hahahaha
Nothing wrong with testing on lots of dynos. Just make sure to hit up a dynojet so you can see where it's "really" at.


Burger Motorsports
Home of the JB4 the worlds most popular turbocharged tuning system!

It is the sole responsibility of the purchaser and installer of any BMS part to employ the correct installation techniques required to ensure the proper operation of BMS parts, and BMS disclaims any and all liability for any part failure due to improper installation or use. It is the sole responsibility of the customer to verify that the use of their vehicle and items purchased comply with federal, state and local regulations. BMS claims no legal federal, state or local certification concerning pollution controlled motor vehicles or mandated emissions requirements. BMS products labeled for use only in competition racing vehicles may only be used on competition racing vehicles operated exclusively on a closed course in conjunction with a sanctioned racing event, in accordance with all federal and state laws, and may never be operated on public roads/highways. Please click here for more information on legal requirements related to use of BMS parts.
Reply With Quote
(#22)
Old
DSCOFF's Avatar
DSCOFF DSCOFF is offline
Senior Member

Posts: 534
Join Date: Jun 2013
Car: 335i coupe N54
Default 10-30-2014, 09:14 PM

Quote:
Originally Posted by trebila
great log.

as long as your AFRs stay between 12.6-12.9, your timing will be good.

can you do a 3-4 gear upshift with your AT, to check your postshift timing recovery ?
Actually did one run in S mode, and yes it did Flatline! Any easy fixes? LOL Car felt quick though through 4th and I did not even suspect it until I looked at the logs.


2009 N54 335i coupe, 6AT PD trans, Stage 3 XHP, Built Motor, 9.6:1 Comp Ratio, Ported Head, Trebilia Custom Flash, JB4, Mhd flasher, Ngk 97506 0.018 gapped, PI Kit 100% E85, Jb4 PI integration, Stage 2 Pure Turbos 25.6psi, 17.2 deg timing, TFT inlets, Stage 3 Fuel-it Fpr, FBO, 431rwkw Mainline Dyno Aus

2016 M4 Competition Pack, 7-sp DCT, Jb4 Map 6
25.0 psi, s55 ign e85 Bef, E70, M4 plugs gapped 0.020, stock everything else, 374.9 rwkw Mainline Dyno Aus
Reply With Quote
(#23)
Old
rac rac is offline
Junior Member

Posts: 145
Join Date: Mar 2014
Car: 2008 135i 6MT
Default 10-30-2014, 10:30 PM

Quote:
Originally Posted by DSCOFF
Unfortunately in Australia, I cannot find anyone offering Dynojet dynos

And most of our Dyno Dynamics and Mainline dynos ones are always 15-20% under Dynojet results in the US especially if in shootout mode. But yeah, these dynos can be manipulated up or down for that matter quite easily.
where are you located? i found one in perth. email dynojet if their dyno center map isnt working, which i tried just now and it isn't.
Reply With Quote
(#24)
Old
Bullitt1841's Avatar
Bullitt1841 Bullitt1841 is offline
Legend

Posts: 1,497
Join Date: Aug 2011
Car: '07 335i Sedan, Built & Blown '08 Mustang Bullitt
Default 10-30-2014, 10:30 PM

Quote:
Originally Posted by Terry @ BMS
Nice runs Ken but sorry to break some bad news. This is not a dyno record. Dyno records can only be set on dynojet machines. It's because DD, MD, and other types of dynos show wildly varying numbers based on their correction factors and other settings. I have had customers email in reporting 500whp on DD machines stock turbo, lol. It's meaningless. It needs to be done on a dynojet to count which has proven to be very consistent day to day and machine to machine. And most importantly there are no settings to adjust to get higher or lower figures.

In fact I think we had this same conversation 2-3 years ago at shift sector when you told me you dynod at 500whp on stock turbos. And I said it was impossible. Turns out you were using an MD dyno and when you went to a dynojet only did 440whp, if memory serves? For tuning MD & DD are fine. But for records its dynojet or nothing.

Anyway go run it on a dynojet and you'll probably get the same 450-460whp everyone else gets running the same boost and timing levels. Maybe you'll even break our record. But to get up to 480whp for the current stock record we really had to pull out all the stops! It can be repeated but it won't be with an automatic IMHO.
+1

Variable load dyno's *can* (not *will*) vary a lot with the same vehicle and even the same session. Fixed mass dyno's simply don't vary due to inherently less variables (i.e. operator input). If you don't have repeatability, you have nothing meaningful as far as comparison goes. Doesn't anybody know what a Gage R & R is?


2018 Audi RS3 | APR Stage 1 E85 and 91 Flashes | JB4 for Logging

SOLD: 2017 F36 440i Gran Coupe | PS2 | MPPSK | Track Handling Package | JB4

SOLD: 2007 E90 335i | PS2's | JB4 | FBO | 160k+ miles on the car, 120k+ miles on the JB4

Log, log, then log some more...
Reply With Quote
(#25)
Old
Curare86 Curare86 is offline
Junior Member

Posts: 80
Join Date: Dec 2012
Car: 135i
Default 10-31-2014, 09:56 PM

Quote:
Originally Posted by rac
where are you located? i found one in perth. email dynojet if their dyno center map isnt working, which i tried just now and it isn't.
damn you beat me to it, Im in Perth too and was just about to suggest the DJ website with the dyno map
sorry to get off topic wedge
Reply With Quote
Reply


Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)

Thread Tools Search this Thread
Search this Thread:

Advanced Search
Display Modes

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off

Forum Jump




vBulletin Skin developed by: vBStyles.com
Copyright 2007 - 2020, N54tech.com
